MOTOCRANE TITAN LT
STABILIZED REMOTE HEAD
Compact Size, Legendary Strength.
Real 40lbs payload capacity.
Around half the size of its big brother, with all the power, strength and features you’d expect from a TITAN. LT features a 20% larger build volume than the Ronin 2 for easier and safer mounting of larger payloads.
Machined from 6061 aluminum, and uses massive bearings, axles, and hardware that you can trust at the limits of performance.
PRECISION: New slotless motors and GPS satellite tracking provide rock-solid stability.
STRENGTH: The revolutionary, unified 6061-T6 billet aluminum mechanical structure provides a class leading 40 lb payload capacity.
SPEED: Optimized design and 10Nm of peak torque allow for dynamic and aggressive applications, including gimbal operation at over 100mph.
SLIPRINGS: 3-axis gimbal equipped with sliprings for completely unrestricted & infinite movement on all 3 axis.
CONTROL: A modular system with an easy to navigate touch-screen interface, joystick or wheels control, and wired or wireless connectivity.
RAIN or SHINE: Weather resistant and rated for temps from -30ºF to 120ºF
Mechanical
-
Construction: 6061-T6 Aluminum chassis
-
Maximum operational speed: 130+mph
-
Max Pan motor torque: 10Nm
-
Max Pan speed: 360º/sec
-
Maximum Payload Capacity: 40lbs/18kg
-
Dry Weight: 18lbs/8.2kg
-
Weather rating: IP65 (water resistant)
-
Temperature rating: -30ºF - 120ºF
-
Gimbal Mounting: Mitchell mount adapter, LT Quick Disconnect
-
Payload mounting: DJI R2 Dovetail/Baseplate
-
Camera build volume: 270mm (L) x 225mm (W) x 236mm* (H)
*286mm height with 50mm Cage Extension accessory
Electrical
-
System Voltage: 48V (42-52VDC)
-
Comms: CAN-BUS, hardwired + 2.4Ghz wireless
-
Power output: 3x 14.4V 2-Pin LEMO (125W) + 1x 26V (125W), 250W combined
-
Lens Driver: 3-channel, digital 7-pin LEMO
